Specifications

Pressure :4-25cm H2O

Weight:   132g for Standard & Small (1 frame + 1 cushion + 1 headgear + 1 elbow)

Materials: Silicone elastomer, polycarbonate, nylon/elastane

Replacement Parts

Accessories

This product does not have accessories

Packing List

• Frame in Selected Size with Elbow

• Small, Medium, Small Wide Cushions

• Headgear

Support

Warranty:30 days satisfaction guaranteed

Please see below for expert hints on keeping your equipment in good condition.

User guide - download the User guide for detailed information regarding your mask.

Sizing the Frame:

Step 1 - in general, men should select the Standard frame size and women should select the Small frame size. These are general recommendations that can be disregarded if you feel that you have a smaller/larger face than average.

Step 2 - the frame should sit on the top of the head, like a headband. If the frame is too small, it will feel tight and sit too close to your forehead. If the frame is too large, it will feel loose and sit too far back on your head.

Sizing the Cushion:

Step 1 - print the Sizing Template, ensuring it is printed to scale.

Step 2 - place the template below your nose, perpendicular to your face. If you have a narrow nose, start with the blue/red side of the template. If you have a wide nose, start with the black/purple side of the template.

Step 3 - look into a mirror and assess whether your nose falls inside or outside the margins on the template. If you are between two sizes, choose the larger one.

Step 4 - if your nose is size S (red) or M (blue), select the appropriate cushion from your starter pack. If your nose is SW (purple) or W (black) then you will need to order the cushion as a spare part.

If you don't want to use the sizing template, refer to our sizing guidelines in the table below. Use a straight ruler to measure the width of your nose.
